GTX2860R Garrett Gen II Turbocharger 856800-5001S

€1,553.76
Content: 1 Stück

Prices incl. VAT plus shipping costs

Ready to ship today,
Delivery time appr. 1-3 workdays

  • 856800-5001S
Horsepower: 200 - 475 HP Displacement: 1.4 - 2.5 L V-Band Inlet - V-Band Outlet - Single... more
GTX2860R Garrett Gen II Turbocharger 856800-5001S

Horsepower: 200 - 475 HP
Displacement: 1.4 - 2.5 L
V-Band Inlet - V-Band Outlet - Single Scroll - A/R 0.57

  • Gen II Aero forged milled compressor wheel
  • High-Flow Compressor Housing with integrated speed sensor port
  • Rotation: Standard (Clockwise)
  • Dual ceramic ball bearing cartridges
  • Inconel Turbine Wheel
  • Water- and Oil Cooled
  • External Wastegate
  • Replaces: 836040-5002S
Compressor side:
Inducer ø
46.00mm
Exducer ø
60.00mm
Trim
58
A/R
0.60
Turbine side:
Inducer ø
54.00mm
Exducer ø
47.00mm
Trim
76
A/R
0.57

This set contains the following items:
